G5p Pulse electric fence
As for the pulse electric fence, the pulse generated by the energizer is transmitted to each front-end alloy wire through high-voltage insulated wires. In case of climbing and destruction, it will cause short circuit to the two adjacent alloy wires and trigger the alarm, which has the functions of blocking and deterrence.
Product parameters
G5p Pulse electric fence
Main power supply
AC220V (power adapter), DC24V, AC24V
Backup power supply
DC12V battery
Operating environment
temperature: -40℃~+80℃ relative humidity ≤95%
Alarm delay
≤2s
Power
Maximum power 15W
Communication interface
RS485 or network interface
Alarm output interface
1 channel per guarding area, normally open, normally closed, public
Power output interface
1 DC12V 800mA output
Alarm input
1 channel
Dimensions
290*205*96mm
G5p display size
4.5 inches
